Polymer architecture — specimen index

Engineered substrates for the tactile obsessed.

Explore specimens Layer schematic

Greenguard 5+ yr UV

Caliper spectrum

mil 2.4 – 12.0

From eggshell film to armoured floor vinyl

Peel adhesion, 180°

lb/in 1.2 – 6.8

Measured on stainless steel at 20 minutes

Outdoor UV rating

years 5+ years

Vertical exposure, temperate latitudes

Ink compliance

Certified Greenguard

Low-VOC UV gel, food-contact safe outers

Five-tier stratified substrate architecture.

A finished sticker is five engineered layers. Select a tier to see what it does and how thick it runs.

Tier 01 · surface0.9 mil

UV-absorbing cast polyvinyl fluoride

The optical shield. Blocks the wavelengths that fade pigment and keeps the surface scuff-free under a thumbnail.

Tier 02 · image0.4 mil

Dual-pass pigmented UV gel with spot white

Two ink passes with a white underbase, so colour sits the same on clear, kraft and holographic stock.

Tier 03 · structural2.0 – 8.0 mil

Cast polymeric vinyl or diffractive prism matrix

The body of the sticker. Cast vinyl for conformability, prism film when the piece needs to throw a rainbow.

Tier 04 · adhesive1.1 mil

Micro-grooved pressure-sensitive solvent acrylic

Air-egress channels let trapped bubbles escape during application, then the glue flows flat and closes them.

Molecular substrate vault.

Four speciality films kept in constant stock, with the numbers that decide whether they suit your surface.

Diffractive prism

Prismatic rainbow holographic foil

6.2 mil

Micro-embossed diffraction grating reflects a full spectrum, with a white spot layer printed underneath so artwork keeps its own colour.

Peel adhesion: 5.1 lb/in
Thermal range: −20 °C to 80 °C
Solvent rating: Resistant to alcohol
Best for: Collector and drop runs

See die-cut lines

Botanical kraft label wrapped around a glass jar

Organic pulp

Heirloom botanical textured kraft

5.4 mil

Uncoated recycled pulp with visible fibre through the print. Colour renders warm and slightly muted, which is the reason people choose it.

Peel adhesion: 3.2 lb/in
Water tolerance: Splash only
Disposal: Repulpable, FSC pulp
Best for: Jars, boxes, preserves

See label lines

Armoured decal vinyl applied to a scuffed surface

Ballistic grade

Heavy-armour turf-shield decal vinyl

12.0 mil

The thickest film we stock, laminated with a grit-textured topcoat. Engineered for aisles, loading bays and anywhere carts roll.

Peel adhesion: 6.8 lb/in
Slip rating: R10, wet tested
Abrasion: 1,200 Taber cycles
Best for: Floors, ramps, concrete

See decal lines

Anti-tamper

Tamper-destructible eggshell film

2.4 mil

Brittle by design. Any attempt to lift the seal fractures the face stock into flakes and leaves a void pattern on the surface.

Peel adhesion: 4.4 lb/in
Removal: Destroys on lift
Numbering: Serial or barcode
Best for: Warranty and evidence seals

See security lines

Haptic finishes and specialty varnish lab.

Finishes change how a sticker feels before anyone reads it. The bars show relative surface relief measured across the print.

Spot raised 3D UV varnish

Clear gel built up in passes so a logo stands proud of the surface and catches the light at an angle.

Surface relief92 µm

Hot-stamped metallic foil

Real foil pressed under heat in gold, copper or graphite. Mirror bright, with a hard edge that print cannot fake.

Reflectance96% GU

Selective white underbase

An opaque white layer printed only where it is needed, keeping the rest of the film clear or holographic.

Opacity94% ISO

Soft-touch velvet matte

A suede-feel laminate that kills glare and hides fingerprints. The one people rub with a thumb without meaning to.

Gloss level6 GU

ASTM environmental torture-test matrix.

Each stock is run through the same five abuse tests before it is approved for sale. Results below are for cast vinyl with gloss laminate.

Stress vector	Test method	Chamber parameters	Duration	Result
Dishwasher high heat	ASTM D1308	70 °C wash, alkaline detergent	500 cycles	No edge lift · full retention
Sub-zero cold storage	ASTM D3330	−20 °C freezer, 90% humidity	30 days	Zero shrink-back
Xenon arc accelerated UV	ASTM G155	0.35 W/m² irradiance at 340 nm	2,000 hours	ΔE 1.2 · colour stable
Chemical solvent rub	ASTM D5402	Isopropyl alcohol, weighted rub	100 double rubs	No ink transfer
Taber mechanical abrasion	ASTM D4060	CS-10 wheel, 1,000 g load	1,200 cycles	Legible · no substrate burn

Tactile sampler · edition 04

Feel before you press: the lab specimen box.

Screen resolution is an illusion — weight, grain and grip only happen in your hands. The box holds sixteen printed die-cut swatches, one of every film we stock, plus a laser-etched caliper comparison card.

16 printed die-cut material tiles
4 holographic spectrum swatches
12.0 mil turf-shield floor sample
100% recycled kraft mailer

Free worldwide dispatch · ships in 48 hours · credited against your first order

The lab specimen box

$9.00

Edition 04 · 18 specimens · in stock
